Moving soil, gravel, and demolition waste to a separate screening plant adds transport and handling costs. A Mini Excavator Screening Bucket lets contractors screen material directly on site, reduce repeated hauling, and recover reusable soil and aggregate.
Unlike an excavator auger attachment, an excavator pile driver, or an excavator rock saw attachment, a screening bucket separates soil, gravel, and mixed debris. The excavator loads the bucket and moves material across the screen. Smaller particles pass through the openings, while larger pieces remain inside. This process suits earthmoving, landscaping, construction waste handling, and material recovery.
Mini Excavator Rotary Screening Bucket Specifications
| Product Model | YGGTS-03 | YGGTS-06 | YGGTS-12 | YGGTS-16 | YGGTS-20 | YGGTS-24 |
| Applicable Tonnage of Excavator(T) | 5-10 | 10-18 | 18-25 | 20-30 | 25-35 | 30-40 |
| Total Machine Weight (kg) | 500 | 950 | 1320 | 1800 | 2000 | 2800 |
| Bucket Capacity (m³) | 0.3 | 0.6 | 1.2 | 1.6 | 2 | 2.4 |
| Operating Pressure (MPa) | 20 | 20 | 20 | 20 | 20-25 | 20-25 |
| Recommended Flow Rate (L/min) | 60 | 80 | 100 | 100 | 150 | 150 |
| Screen Mesh Size | 5-50 | 5-80 | 5-100 | 5-120 | 20-120 | 20-120 |
How Does a Rotary Screening Bucket Work?
Hydraulic power drives the bucket’s rotary screening mechanism. As material moves through the bucket, smaller particles pass through the mesh while larger pieces remain inside.
This process lets crews screen material near the excavation or demolition area. They can reuse suitable soil and aggregate instead of transporting every load to a separate plant. A rotary screener bucket attachment also combines material handling and screening within the same excavator work cycle.
Key Features of the Rotary Screener Bucket Attachment
Built with heavy-duty, hardened wear-resistant steel, YG rotary screening buckets feature a quick-change screen mesh design for easier maintenance and flexible screening. The high-torque hydraulic motor supports stable rotation under heavy loads. YG also offers OEM service and custom mesh sizes, backed by after-sales support for dealers and contractors worldwide.
Wear-Resistant Steel Construction
Abrasive soil, gravel, and broken concrete can wear bucket surfaces during repeated operation. Hardened wear-resistant steel suits demanding material-handling conditions and supports long-term use on construction and recycling sites.
Quick-Change Screen Mesh
Mesh size determines which particles pass through the bucket. The quick-change screen mesh design makes maintenance and mesh replacement easier when screening requirements change. Specify the required particle size when requesting a quotation.
High-Torque Hydraulic Motor
The hydraulic motor drives the rotary mechanism and supports stable rotation under heavy loads. Correct hydraulic flow and pressure remain important for reliable operation. Check compatibility with the excavator’s hydraulic system before selecting a model.
OEM and Custom Mesh Options
YG supports OEM service and custom mesh sizes for different applications and distribution requirements. Dealers and contractors can discuss product specifications and branding needs with the sales team.
Where Can You Use a Soil Screening Bucket for Excavator?
- Landscaping and topsoil preparation: Remove stones and coarse debris before reusing soil for planting or ground restoration.
- Construction and demolition: Separate suitable material from mixed debris and reduce the volume sent for disposal.
- Gravel and aggregate processing: Screen material by particle size before reuse or further processing.
- Roadwork and earthmoving: Process excavated soil near trenches, embankments, and road construction areas.
A demolition screening bucket suits material recovery when the incoming material matches the attachment’s operating limits. Screening material on site can cut haulage costs by reducing repeated trips to a separate screening location.
How Do You Choose a Rotary Screening Bucket for Sale?
Consider these factors before selecting a model:
- Excavator compatibility: Match the attachment to the supported carrier weight range.
- Hydraulic output: Check the excavator’s available flow rate and operating pressure.
- Required particle size: Select mesh openings that match the intended output.
- Material conditions: Consider wear protection for abrasive materials.
- Workload: Match bucket capacity to the volume handled per cycle.
- Supplier support: Request details about warranty coverage, spare parts, and after-sales service.
When contacting an excavator screening bucket manufacturer, provide the excavator make and model, hydraulic specifications, material type, and required mesh size. These details help the supplier identify a suitable model and prepare an accurate quotation.
FAQ
Which Excavator Sizes Do YG Screening Buckets Support?
The YGGTS series covers excavators from 5 to 40 tons, with bucket capacities ranging from 0.3 to 2.4 m³.
What Materials Can a Rotary Screening Bucket Process?
A rotary screening bucket attachment processes soil, gravel, sand, and selected construction or demolition materials. The suitable mesh size depends on the required particle size and material characteristics.
Can I Order a Rotary Screening Bucket With Custom Mesh Sizes?
Yes. YG supports custom mesh sizes for different screening requirements. When requesting a quotation, share your target particle size, excavator model, and material type so the team can discuss suitable options.
Does YG Offer a Warranty?
Contact the sales team for the applicable warranty period, coverage, spare parts arrangements, and after-sales support for your order.
Request a Rotary Screening Bucket Quotation
Looking for a reliable rotary screening bucket for sale? Contact YG Machinery with your application details and screening requirements. Our team will discuss suitable options, available customization, warranty coverage, and after-sales support for your project. Send your inquiry today to request a tailored quotation.
