Not every wood processing job requires a large machine. Small contractors, orchard growers, property managers, and landscaping teams often need a machine that can process branches without taking up too much space. A compact wood chipper turns pruning waste, branches, and small logs into wood chips for mulch, biomass use, or disposal.
Compact Wood Chipper Specifications
| Parameter | YG6130 | YG6140 | YG6145 | YG6145-P | YG6175-P |
| Power type | Diesel or electric engine | Diesel or electric engine | Diesel or electric engine | Diesel or electric engine | Diesel or electric engine |
| Capacity | 2t/h | 3t/h | 5t/h | 5t/h | 8t/h |
| Diesel engine power | 23.6kw/32hp | 40kw/54hp | 75kw/100hp | 75kw/100hp | 145kw/197hp |
| Speed (r/min) | 2600 | 2900 | 2500 | 2500 | 2500 |
| No. of Blade | 4pcs moving knives, 1pcs fixed knives | 4pcs moving knives, 1pcs fixed knives | 4pcs moving knives, 1pcs fixed knives | 4pcs moving knives, 1pcs fixed knives | 8pcs moving knives, 1pcs fixed knives |
| Blade length | 155mm | 155mm | 230mm | 230mm | 260mm |
| Dia of feeding roller | 280mm | 280mm | 500mm | 500mm | 600mm |
| Feeding size | 300*180mm | 300*280mm | 450*380mm | 450*380mm | 550*430mm |
| Feeding method | Horizontal hydraulic feeding | Horizontal hydraulic feeding | Horizontal hydraulic feeding | Horizontal hydraulic feeding | Horizontal hydraulic feeding |
| Feeding chain plate size | / | / | / | 1700*450mm | 3000*550mm |
| Start Method | Electric start | Electric start | Electric start | Electric start | Electric start |
| Start power | 600w | 600w | 800w | 800w | 800w |
| Battery | 12V 105aH | 24V 85aH | 24V 105aH | 24V 105aH | 24V 105aH |
| Crushing diameter | ≤130mm | ≤140mm | ≤250mm | ≤250mm | ≤300mm |
| Fuel tank capacity | 20L | 20L | 25L | 25L | 50L |
| Gear position | Intelligent control | Intelligent control | Intelligent control | Intelligent control | Intelligent control |
| Tire size (Aluminum alloy hub) | 165/70r13 | 165/70r13 | 215/75r15 | 215/75r15 | 215/75r15 |
| Discharge direction | 360° | 360° | 360° | 360° | 360° |
| Other accessories | Tail lights, feed lights, folding jacks | Tail lights, feed lights, folding jacks | Tail lights, feed lights, folding jacks | Tail lights, feed lights, folding jacks | Tail lights, feed lights, folding jacks |
What Makes a Compact Wood Chipper Practical?
Space-Saving Design
Compact equipment takes up less storage space than many large industrial machines. Folding jacks and a rotating discharge chute make storage and positioning easier. These features can be useful for contractors who move equipment between properties or store machinery during the off-season.
Feeding and Cutting Performance
The five models cover different processing needs. The YG6130 has a rated capacity of 2 t/h and a maximum crushing diameter of 130 mm. The YG6175-P reaches 8 t/h and handles material up to 300 mm in diameter. Horizontal hydraulic feeding moves branches toward the cutting system, while the P models include feeding chain plates.
Actual output varies with wood species, moisture, branch shape, and feeding conditions. Buyers should base their selection on the material they process most often rather than capacity alone.
Compact vs. Industrial Wood Chipper: Which One Do You Need?
| Factor | Compact Wood Chipper | Industrial Wood Chipper |
| Typical users | Small contractors, orchard growers, property maintenance teams | Large tree-care companies, forestry operations, municipal services |
| Worksite | Orchards, gardens, residential properties, narrow-access areas | Larger job sites and fixed processing yards |
| Mobility | Designed for work that moves between locations | Often requires more transport planning |
| Processing needs | Routine branch clearing and small to medium workloads | Heavy workloads and continuous bulk processing |
| Storage | Generally needs less space | May require a larger storage or operating area |
| Purchasing considerations | Access, transport, daily volume, and branch diameter | Processing volume, working hours, site layout, and material flow |
Where Can You Use a Compact Wood Chipper?
Orchards and Vineyards
Pruning creates piles of branches that take up space between rows. A compact wood chipper can process this material near the work area, reducing the need to move loose branches to another location. The resulting chips may be used as ground cover when they meet the needs of the orchard or vineyard.
Before purchasing, consider row spacing, turning room, and the largest branches you need to process.
Landscaping and Property Maintenance
Landscaping crews deal with branches from pruning, garden renovation, and storm cleanup. Chipping reduces the size of this waste, making collection and transport easier. Property managers, parks teams, and grounds maintenance contractors may also use compact equipment for routine vegetation work.
The 360° discharge direction allows operators to direct chips toward a suitable collection point. For work near homes or public areas, consider local noise restrictions and site access.
Biomass and Wood Recycling
Wood chips can serve as mulch or as raw material for certain biomass and wood processing operations. However, downstream facilities may require specific chip sizes, moisture levels, and material quality. Confirm these requirements before using the machine to prepare feedstock for another production process.
Diesel or Electric Power for Compact Wood Chipping?
The five listed models offer diesel or electric power configurations. Diesel power can work well at outdoor sites without a convenient electricity supply. The listed fuel tank capacities range from 20 to 50 liters.
An electric configuration can be used where a compatible power supply is available. It produces no exhaust emissions at the point of use, although total environmental impact depends on the electricity source. Noise levels and operating costs also vary by configuration and working conditions.
Before ordering an electric model, confirm voltage, frequency, motor power, and available electrical capacity. For a diesel model, ask about fuel consumption and the recommended maintenance schedule.
Maintenance Tips for Longer Service Life
Regular maintenance helps keep the cutting and feeding systems in working condition.
- Blades: Inspect cutting edges regularly and sharpen or replace them when needed.
- Hydraulic system: Check oil levels, hoses, and connections for leaks. Use the specified hydraulic oil.
- Bearings and drive parts: Lubricate components according to the manufacturer’s maintenance schedule.
- Tires and battery: Inspect tire pressure, wheel fasteners, and battery condition before transport or operation.
- Discharge chute: Remove accumulated chips after use and inspect the chute for blockages or damage.
Always shut down the machine and follow the manufacturer’s safety procedures before clearing blockages or servicing moving parts.
FAQ
Can a compact wood chipper handle hardwood branches?
Yes, if the material stays within the model’s rated crushing diameter. Hardwood type, branch shape, and moisture content can affect feeding speed and output.
What is the maximum branch diameter these models can process?
The listed maximum crushing diameter ranges from 130 mm for the YG6130 to 300 mm for the YG6175-P. Confirm the specifications for the selected model before processing large branches.
Can I tow a compact wood chipper with an SUV or pickup?
That depends on the machine’s weight, towing configuration, vehicle capacity, and local road regulations. Confirm these details before arranging transport.
Can the discharge chute direct chips into a truck or collection bin?
All five listed models have a 360° discharge direction. The chute can be positioned toward a collection area, provided the setup allows safe operation and the collection point is within reach.
Contact YG Machinery for Wood Processing Equipment
If you need a compact wood chipper for sale, contact YG Machinery for model specifications, configuration details, pricing, and delivery information. Besides compact wood chippers, YG Machinery also supplies a range of related equipment, including the industrial wood chipper, log splitter, and wood cutter splitter for wood processing work. For outdoor maintenance and site management, the product range also includes the remote control lawn mower and fog cannon. Contact YG Machinery to ask about the specifications and availability of these machines.
