Road Sweeper Truck is a truck-mounted cleaning vehicle for large-area pavement maintenance. It combines sweeping, vacuum collection, dust suppression and debris unloading functions in one machine, helping reduce manual cleaning work for roads, industrial areas and commercial pavement. It commonly serves daily street cleaning, industrial area maintenance and construction site dust control.
Road Sweeper Truck Specifications
| Parameter | Specification |
| Chassis Model | EQ1125SJ8CDC |
| Gross Weight | 11,995 kg |
| Curb Weight | 7,400 kg |
| Rated Load Capacity | 4,400 kg |
| Clean Water Tank | 4 m³ |
| Garbage Box | 5 m³ Stainless Steel |
| Sweeping Width | 2,800 – 3,200 mm |
| Sweeping Speed | 3 – 15 km/h |
| Maximum Sweeping Capacity | 38,000 m²/h |
| Garbage Pickup Rate | ≥ 96% |
| Side Brushes | 2 |
| Brush Diameter | φ800 – 900 mm |
| Brush Speed | 140 r/min |
| Suction Pipe Diameter | φ180 mm |
| Suction Airflow Speed | 50 – 65 m/s |
| Nozzle Negative Pressure | 380 mmH₂O |
| Nozzle Ground Clearance | 5 – 8 mm |
The main engine options include Yunnei D25TCIF1 at 150 HP and Yuchai YCY30165-60 at 165 HP. The auxiliary engine uses Dongfeng Cummins B140 33 with 102 kW power to support the cleaning system.
Applications of the Truck-Mounted Road Sweeper
The truck-mounted structure allows this cleaning vehicle to handle regular cleaning tasks across large paved areas.
Typical applications include:
- Municipal roads: Supports urban road maintenance, street cleaning and public pavement management.
- Industrial parks: Removes dust, sand and production-related debris from factory roads.
- Construction sites: Cleans access roads and paved working areas affected by dust and loose materials.
- Parking areas: Maintains large outdoor parking surfaces.
- Commercial areas: Helps keep public and business spaces clean.
In addition, the machine works well in dry environments where dust and sand accumulation require frequent cleaning. The combination of sweeping, vacuum collection and dust suppression functions helps maintain cleaner pavement surfaces.
How the Vacuum Sweeping and Dust Suppression System Works
This cleaning vehicle combines mechanical sweeping, vacuum collection and dust suppression functions.
During operation, hydraulic side brushes first move debris toward the suction area. Then, the vacuum system transfers dust, sand, leaves and other waste into the garbage box.
Meanwhile, the water spray system helps reduce airborne dust during cleaning, especially in dry environments. Proper adjustment of brush pressure and suction settings helps maintain cleaning performance and reduce component wear.
How to Choose the Right Sweeping Equipment for Different Road Conditions
Selecting suitable cleaning equipment depends on the working environment, debris type and daily cleaning requirements.
- Road Width: Wider roads and large paved areas usually require a larger sweeping range to reduce repeated cleaning passes.
- Debris Type: Dust, sand, leaves and construction waste may require different suction and brush settings to maintain cleaning performance.
- Water Supply: Long cleaning routes should consider water availability and refilling arrangements for continuous operation.
- Working Hours: Projects with longer daily operation times should consider fuel consumption, maintenance frequency and wearing part replacement.
- Local Requirements: Before export or road operation, confirm emission standards, vehicle registration, import documents and after-sales support requirements.
Maintenance and Operating Notes for Sweeping Equipment
Regular maintenance focuses on components that directly affect cleaning performance. Side brushes, suction pipes, hydraulic parts and spray nozzles need regular inspection to maintain stable operation.
Key maintenance areas include:
- Sweeping and suction system inspection
- Hydraulic component maintenance
- Water spray system cleaning
In addition, operating costs depend on fuel consumption, water usage, maintenance frequency and wearing parts. Actual consumption varies according to chassis configuration, working conditions and cleaning requirements.
Get the Right Cleaning Equipment Recommendation
From road width and debris conditions to daily cleaning requirements, the right configuration depends on the actual working environment.
YG Machinery provides technical details, quotation support and suitable cleaning equipment options for different project requirements. Contact us to discuss your cleaning needs and equipment configuration.
Road Sweeper Truck FAQ
What is a truck-mounted vacuum sweeper used for?
A truck-mounted vacuum sweeper collects road dust, sand, leaves and other debris from large paved surfaces. It commonly serves municipal roads, industrial parks, construction areas and parking facilities that require regular cleaning.
How do I choose a Road Sweeper Truck for municipal road cleaning?
The selection depends on road width, daily cleaning distance, debris volume, operating hours and local regulations. Large urban roads usually require higher cleaning coverage, while industrial areas may need stronger debris collection capability.
Can this cleaning vehicle work in dusty areas?
Yes. The sweeping and dust suppression functions support cleaning in environments with high dust levels. Proper brush adjustment and regular maintenance help maintain cleaning performance.
What affects the operating cost of a road cleaning truck?
Operating costs mainly depend on fuel consumption, water usage, maintenance requirements, brush wear, hydraulic system service and spare part replacement.
How often should the sweeper brushes be replaced?
Brush replacement depends on working hours, road surface conditions and debris type. Rough pavement and heavy debris usually increase brush wear.
What should be confirmed before purchasing cleaning equipment?
Buyers should check road conditions, cleaning area, debris type, water supply, emission requirements, registration regulations and available after-sales support before purchase.
